Parametric design

What does parametric design even mean in our industry? For the first blink: strange, out of this world buildings, with unique shapes. In reality, parametric design holds much more than that with proper tools.
Our in-built solution, Descript facilitates parametric design inside Consteel, while our plugin, Pangolin helps to exploit the possibilities of Rhino-Grasshopper.
Explore how to shift during design from the actual geometry to the underlying logic!

No credit card required

Specific Feature Solutions for Parametric design in Consteel

Parametric model building in Grasshopper – Pangolin

In the dynamicly evolving landscape of structural design, Consteel’s Pangolin plugin for Grasshopper revolutionizes parametric model building, analysis and design. By seamlessly integrating Consteel’s powerful capabilities within Grasshopper’s intuitive visual programming environment, Pangolin empowers engineers to create complex structural models with unprecedented flexibility and efficiency.

Model optimization by in-built scripting environment

Optimizing structural models is never a simple task—it demands well-defined criteria and a purposeful, iterative algorithm. One common approach is cross-section optimization, and for this, Consteel provides practical solutions through easily accessible and user-friendly Descript scripts. What’s more, these scripts can also be utilized within the Grasshopper environment thanks to Pangolin.

ReferenceS by OUR users

How can Consteel enhance your work?

Hungexpo Project, Arrival Hall

A real case study on advanced parametric BIM workflow.

The Hungexpo Budapest Fair is going through a massive revitalization. This project includes the new Arrival Hall Building, an attractive propeller-shaped building. A building with such geometric complexity requires advanced design methods and multi-platform collaboration. In this article, we aim to give an insight into the open BIM environment and parametric design methods used in the design process.

The design processes of a multi-story industrial structure using a central parametric model

Discover an in-depth case study detailing the expansion of a Turda, Romania plasterboard factory, which shows how the expansion led to the construction of nine new structures. This project, which uses a central parametric model, won third place in this year’s The Steel Lion Award 2023 competiton, thanks to its innovative use of Consteel software for steel structural design and Pangolin, the Rhino-Grasshopper plugin for Consteel.

A complete structural parametric design workflow of a slide support structure

We present one of the projects for the Steel Lion Award, which won this year’s Pangolin Award. In this article you can read a detailed case study from the Tiszaliget Revitalization project.
The main task of the structural engineers was to carry out the design of a support structure for a new slide track. This was prescribed by the architectural design to have slightly different slopes and curvatures than the existing ones which have been considered obsolete.

Innovative formwork design with Pangolin

Introducing the one of the winners of The Steel Lion Award 2024. The article includes a detailed case study of Pangolin design for the creation and design of formwork structure.
Control throughout the design process is crucial, and even more so when it comes to structures whose loads change throughout the design process, as they are the result of a phased analysis that aims for an optimum.The field of special formwork is one of these areas.
Structures that: must support large loads (weight of fresh concrete) without showing large deformations to obtain the required concrete geometry…

Parametric design of an office building

Introducing the student prize winner of The Steel Lion Award 2024. The project introduces the parametric design and was created by Darius Dumitraşcu, a final year student from Romania.
For Darius Dumitraşcu, the winner of the Student Award, the task was the design of an office building, based on a steel structural system. He proposed to create a fictional building, giving him the freedom of creating any kind of geometry for the structure, which provided him an opportunity to approach the design with parametrization more freely. The final structure was inspired by The Gherkin from London, and it’s diagrid structure.
The next step was to build a parametric model which could help him build up and analyze several models with slightly different geometries by only changing a few parameters, and could be used to generate the final model.

The development of a user-friendly, parametric structural design tool for cold-formed steel modular buildings

Since we entered in the world of parametric design with our Grasshopper plugin Pangolin, we have observed numerous remarkable projects characterized by significant geometrical and structural intricacy. However, these projects are so unique that it is hard to effectively transfer the experiences and standardize certain parts of the parametric design workflow, particularly within design firms employing numerous structural engineers. But what happens in the case of modular or pre-engineered buildings? One of our customers has the answer. Let us delve into the details and then watch the accompanying video for a practical demonstration.
